Drill Collar Severing Tool – Pipe Recovery Operations – 15,000 PSI – API RP-67

Heavy Weight Drill Pipe Cutter

Also known as:

Explosive Bridge Wire Detonator, Pipe Cutting Tool

Drill Collar Severing Tool – Pipe Recovery Operations – 15,000 PSI – API RP-67

Heavy Weight Drill Pipe Cutter

Also known as:

Explosive Bridge Wire Detonator, Pipe Cutting Tool

Buy

Made to Order

Manufacturer

Price:

 Request for Quote

Shipping:

Land freight

Delivery Time:

3 Weeks

Note:

Drill Collar Severing Tools are designed to sever drill collars and heavyweight drill pipe reliably and safely during Pipe Recovery Operations.

Executive Summary

Drill Collar Severing Tools are used to sever drill collars and heavyweight drill pipe reliably and safely during pipe recovery operations. The tool operates using Explosive Bridge-Wire (EBW) Detonators that initiate simultaneous detonations of explosive columns, generating a colliding shock wave that cuts through the tubular with precision.

EBW Detonators provide accurate timing and increased control of the explosive sequence, ensuring consistent and efficient performance. Tension is typically applied to the tubing before detonation to assist in freeing stuck tubulars.

Drill Collar Severing Tools are applied in pipe recovery, stuck pipe, and plug and abandonment (P&A) operations where controlled, precise severing of downhole equipment is required.

Technical Specifications

Type Pipe Recovery Operations
Compliance Standard API RP-67
Weight Less than 100lbs
Shipping Class 1.4S (detonators), 1.4D (pellets)
Operation Explosive Bridge-Wire (EBW) detonation
Assembly On-location
Function Severs drill collars and heavyweight drill pipe
Pressure Rating 15,000 PSI
Max Temp 400 °F
Application Up to 2-7/8” drill pipe severance

Features and Benefits

  • Air shippable at Class 1.4S for detonators and 1.4D for pellet.
  • Hardware shipped separately.
  • Conforms to API RP-67.
  • Utilizes Explosive Bridge-Wire Detonators for increased safety.
  • Explosive Bridge-Wire Detonators increase the precision of the colliding shock-waves for maximum performance.

Print or Share

Do you need information for the team or a client? Download these page to add your dossier.

Email Page

Send an email with the link to this page. It's a great way to share information.

Detailed Description

Drill Collar Severing Tools are used for pipe recovery operations to sever drill collars and heavyweight drill pipe. The tools utilize Explosive Bridge-Wire (EBW) detonators to simultaneously detonate explosive columns, creating a colliding shock wave that severs the tubular with precision.

The tools conform to API RP-67 and are suitable for stuck pipe and plug-and-abandonment (P&A) operations. Detonators are air shippable, and hardware is shipped separately, with assembly performed on location to ensure safe handling and deployment.

EBW detonators increase the precision of the colliding shock waves, providing consistent and controlled severing of tubulars. Tension is typically applied to the tubing prior to detonation to assist in the removal of stuck tubulars and to improve the efficiency of the operation.

These tools are applied in scenarios where accurate, controlled severing is required to recover or remove downhole tubular components safely. They are suitable for a range of tubular sizes and are designed to maintain reliability under the conditions commonly encountered in deepwater, high-pressure, or deviated wellbores.

Drill Collar Severing Tools provide a reproducible method for severing tubulars while minimizing risk to personnel and equipment. Their use ensures that stuck or abandoned tubulars can be removed in a controlled manner, supporting safe and effective pipe recovery operations.

Engineering Data
